Overview

 The Vertiv Geist MNS3E1R6-12CF18-3TL21A0H10-S (also known by the model number NS30207) is a 1U horizontal switched rack Power Distribution Unit (rPDU). It is designed for high-availability IT environments, providing 3-phase power distribution with integrated outlet-level switching and unit-level monitoring.



Specifications

Model Number:  MNS3E1R6-12CF18-3TL21A0H10-S

Brand:  Vertiv

Alt Part Number(s):  NS30207

Product Type:  Power Distribution Unit

Technical Description

Brand:  Vertiv

Model Number:  MNS3E1R6-12CF18-3TL21A0H10-S

Series:  rPDU

Input Phase:  3-Phase

Input Current:  30A

Input Plug:  NEMA L15-30P

Input Voltage:  230 V AC

Frequency:  50 - 60Hz

Output Voltage:  208 V AC

Cord Length:  10ft

Output Connectors Details:  12 x IEC 60320 C13/C19

Power Capacity:  8600 W

Network Interface:  RJ-45 Ethernet

Form Factor:  1U Rackmount

Height:  1.7"

Width:  17"

Depth:   12"
