Overview

The Supermicro MBD-X11SCH-F-B is a high-end Micro-ATX server motherboard featuring the Intel C246 chipset. The "-B" suffix specifically denotes the Bulk Pack version, which typically ships in a plain box with essential accessories for system integrators, such as an I/O shield and SATA cables, rather than full retail packaging.



Specifications

Model Number:  MBD-X11SCH-F-B

Brand:  Supermicro

Alt Part Number(s):  MBD-X11SCH-F-B

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-X11SCH-F-B

Series:  E-2100/E-2200

Processor Type:  Intel Xeon

Processor Core:  8Cores/16 threads

Processor Socket:  LGA 1151 (Socket H4)

Processor Generation:  8th/9th Gen

Chipset Type:  Intel C246

Storage Interfaces:  8 × SATA3 (RAID) + M.2 PCIe 3.0 ×4

Network:  Dual (1GbE) ports powered by the Intel i210 controller

RAID:  RAID 0, 1, 5, and 10

Graphics:  ASPEED AST2500 BMC

Memory Supported:  128GB

Memory Speed:  2666MHz

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  2 × PCIe 3.0 ×8

Error Detection:  ECC

Fan Headers:  Features 6x 4-pin fan headers

TDP:  95W

Form Factor:  Micro-ATX
