Supermicro MBD-H12DSI-NT6-O AMD EPYC 64-Core E-ATX Server Motherboard
Overview
The Supermicro MBD-H12DSI-NT6-O is a high-performance Extended ATX (E-ATX) server motherboard designed for dual AMD EPYC 7000 series processors. The "-O" suffix indicates a retail package, which typically includes the motherboard, an I/O shield, and two SATA cables.
Specifications
Model Number: MBD-H12DSI-NT6-O
Brand: Supermicro
Alt Part Number(s): MBD-H12DSI-NT6-O
Product Type: Motherboard
Technical Description
Brand: Supermicro
Model Number: MBD-H12DSI-NT6-O
Series: 7003/7002
Processor Type: AMD EPYC
Processor Core: 64-Cores
Storage Interfaces: 10 x SATA3 (6Gbps) ports
Network: Dual (10GbE) LAN ports powered by a Broadcom BCM57416 controller
USB: 2 x USB 3.0 ports and 2 x USB 2.0 ports
Graphics: ASPEED AST2600 BMC
Memory Supported: 4TB
Memory Speed: 3200 MHz
Memory Channels: 8‑Channel
Memory Type: DDR4
Memory Slots: 16 DIMM slots
Expansion Slots: 6 total PCIe 4.0 slots
Error Detection: ECC
Power Capacity: 270W
Form Factor: E-ATX
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
