Overview

The MBD-A2SDI-12C-HLN4F-O is a Mini-ITX embedded server motherboard featuring a 12-core Intel Atom® C3858 SoC, 4 DIMM memory support with ECC, intense storage capacity (12 SATA3 + M.2), quad GbE LAN, and IPMI/BMC remote management — ideal for compact servers, NAS/storage appliances, and industrial network systems requiring low power and robust connectivity.



Specifications

Model Number:  MBD-A2SDI-12C-HLN4F-O

Brand:  Supermicro

Alt Part Number(s):  MBD-A2SDI-12C-HLN4F-O

Product Type:  Motherboard

Technical Description

Brand:  Supermicro

Model Number:  MBD-A2SDI-12C-HLN4F-O

Processor Type:  Intel Atom

Processor Model:  C3858

Processor Core:  12-Cores/12 Threads

Processor Core:  2.0GHz

Processor Cache:  12MB

Processor Socket:  BGA-1310

Storage Interfaces:  12 SATA3 (6Gbps) ports

Network:  4x 1GbE ports via the Intel C3000 SoC

USB:  1 × USB 3.2 Gen1 (Type-A), 4 × USB 2.0

Graphics:  ASPEED AST2400 BMC

Memory Capacity:  64GB

Memory Supported:  256GB

Memory Type:  DDR4

Memory Slots:  4 DIMM slots

Expansion Slots:  1 PCIe 3.0 x4 slot

Error Detection:  ECC

TDP:  25W

Power Input:  12V DC

Form Factor:  Mini-ITX
