Overview

Kioxia KCM71VJE3T20 CM7-V is a 3.2TB E3.S PCIe 5.0 NVMe SSD with 3D TLC flash, delivering up to 14,000 MB/s read, 6,750 MB/s write, and 3 DWPD endurance. Built for data center workloads with 2.5M hours MTBF.

Specifications

Model Number:  KCM71VJE3T20

Brand:   Kioxia

Alt Part Number(s):    KCM71VJE3T20

Product Type:  Solid State Drive



Technical Description

Brand:  Kioxia

Model:  KCM71VJE3T20

SSD Capacity: 3.2 TB

Flash Type: 3D TLC

Interface: PCIe 5.0

Max 4KB Random Read: 2,700K IOPS

Max 4KB Random Write: 600K IOPS

MTBF: 2,500,000 hours

Power Consumption (Operational): 24 W

Power / Voltage Required: 12 V ±10%, 3.3 V ±15%

Width: 76 mm ±0.25 mm

Depth: 7.5 mm (+0.2 / -0.5 mm)

Height: 112.75 mm ±0.4 mm

Weight: 110 g

Features: E3.S form factor (7.5 mm), PCIe 5.0, NVMe 2.0 compliant, proprietary KIOXIA controller and 112-layer BiCS FLASH 3D TLC, Open Compute Project Datacenter NVMe SSD v2.0 support

Min Operating Temperature: 0°C

Max Operating Temperature: 76°C

Max Sequential Read: 14,000 MB/s

Max Sequential Write: 6,750 MB/s

Endurance: 3 DWPD
